Chalice Pro
Högkvalitativ LED downlight ger exceptionell effektivitet och lång livstid på LED
- Ledande effektivitet på >110lm/W
- Högpresterande optik och ljuskammare för en enhetlig ljusbild
- UGR (Unified glare ratio) på <19 och CRI 80 för applikationer med höga ljuskvalitetskrav
- Håltagningsmått på 150mm och total höjd på 94mm för att möta specifika designkrav
- ANDRA ALTERNATIV FINNS TILLGÄNGLIGA (utan dimning, nödbelysning etc.) Konfigurationsalternativ finns i myProduct
Utförande
Armaturhölje: Aluminium vitmålad
Frontring: RAL9016
Reflektorfinish: Spektral eller Satin
Installering och montering
Passar infällt takmontage, med håltagningsmått på: Ø150mm. Chalice Pro kan installeras direkt från lådan i flera olika typer av innertak med varierande tjocklek från 1mm-40mm. Driftdonet gör installation och underhåll snabbt och enkelt.
New Product
LumExpress Product
eControl Product
▼ Chalice Pro CRI 80, blank reflektor
| Beskrivning | Armatureffekt (W) | Armaturljusflöde (lm) | Type | Vikt (kg) | SAP nummer | ||||
|---|---|---|---|---|---|---|---|---|---|
| CHAL PRO LED1100-830 HFIX RMB W6 | 9 | 1090 | LED | 0.49 | 96642356 | ||||
| CHAL PRO LED1100-840 BC RMB W6 | 9 | 1100 | LED | 0.57 | 96631226 | ||||
| CHAL PRO LED1100-840 HFIX RMB W6 | 9 | 1100 | LED | 0.49 | 96642357 | ||||
| CHAL PRO LED1400-927-65 HFIX RMB | 22 | 1400 | LED | 0.61 | 96634781 | ||||
| CHAL PRO LED2000-830 HFIX RMB W6 | 16 | 1900 | LED | 0.49 | 96642358 | ||||
| CHAL PRO LED2000-840 BC RMB W6 | 16 | 2030 | LED | 0.57 | 96631225 | ||||
| CHAL PRO LED2000-840 HFIX RMB W6 | 16 | 2030 | LED | 0.49 | 96642359 | ||||
| CHAL PRO LED2000-927-65 HFIX RMB | 29 | 2000 | LED | 0.61 | 96634782 | ||||
| CHAL PRO LED3000-830 HFIX RMB W6 | 25 | 2900 | LED | 0.49 | 96642360 | ||||
| CHAL PRO LED3000-840 HFIX RMB W6 | 25 | 3030 | LED | 0.49 | 96642361 |
▼ Chalice Pro CRI 80, matt reflektor
| Beskrivning | Armatureffekt (W) | Armaturljusflöde (lm) | Type | Vikt (kg) | SAP nummer | ||||
|---|---|---|---|---|---|---|---|---|---|
| CHAL PRO LED1100-830 HFIX RSB W6 | 9 | 1090 | LED | 0.49 | 96642332 | ||||
| CHAL PRO LED1100-840 HFIX RSB W6 | 9 | 1100 | LED | 0.49 | 96642333 | ||||
| CHAL PRO LED1400-927-65 HFIX RSB | 22 | 1400 | LED | 0.61 | 96633613 | ||||
| CHAL PRO LED2000-830 HFIX RSB W6 | 16 | 1900 | LED | 0.49 | 96642334 | ||||
| CHAL PRO LED2000-840 HFIX RSB W6 | 16 | 2030 | LED | 0.49 | 96642335 | ||||
| CHAL PRO LED2000-927-65 HFIX RSB | 29 | 2000 | LED | 0.61 | 96633614 | ||||
| CHAL PRO LED3000-830 HFIX RSB W6 | 25 | 2900 | LED | 0.49 | 96642336 | ||||
| CHAL PRO LED3000-840 HFIX RSB W6 | 25 | 3030 | LED | 0.49 | 96642337 |
▼ Chalice Pro-konfigurerade produkter, CRI 80, blank reflektor
| Beskrivning | Armatureffekt (W) | Armaturljusflöde (lm) | Type | Vikt (kg) | SAP nummer | ||||
|---|---|---|---|---|---|---|---|---|---|
| CHAL PRO LED1100-830 HF RMB W6 | 9 | 1090 | LED | 0.49 | 96642350 | ||||
| CHAL PRO LED1100-840 HF RMB W6 | 9 | 1100 | LED | 0.49 | 96642351 | ||||
| CHAL PRO LED2000-830 HF RMB W6 | 16 | 1900 | LED | 0.49 | 96642352 | ||||
| CHAL PRO LED2000-840 HF RMB W6 | 16 | 2030 | LED | 0.49 | 96642353 | ||||
| CHAL PRO LED3000-830 HF RMB W6 | 25 | 2900 | LED | 0.49 | 96642354 | ||||
| CHAL PRO LED3000-840 HF RMB W6 | 25 | 3030 | LED | 0.49 | 96642355 |
▼ Chalice Pro-konfigurerade produkter, CRI 80, blank reflektor, nödbelysning
| Beskrivning | Armatureffekt (W) | Armaturljusflöde (lm) | Type | Vikt (kg) | SAP nummer | ||||
|---|---|---|---|---|---|---|---|---|---|
| CHAL PRO LED1100-830 HF E3 RMB W6 | 9 | 1090 | LED | 1.51 | 96642362 | ||||
| CHAL PRO LED1100-830 HF E3TX RMB W6 | 9 | 1090 | LED | 1.51 | 96643009 | ||||
| CHAL PRO LED1100-840 HF E3 RMB W6 | 9 | 1100 | LED | 1.51 | 96642363 | ||||
| CHAL PRO LED1100-840 HF E3TX RMB W6 | 9 | 1100 | LED | 1.51 | 96643010 | ||||
| CHAL PRO LED2000-830 HF E3 RMB W6 | 16 | 1900 | LED | 1.51 | 96642364 | ||||
| CHAL PRO LED2000-830 HF E3TX RMB W6 | 16 | 1900 | LED | 1.51 | 96643011 | ||||
| CHAL PRO LED2000-840 HF E3 RMB W6 | 16 | 2030 | LED | 1.51 | 96642365 | ||||
| CHAL PRO LED2000-840 HF E3TX RMB W6 | 16 | 2030 | LED | 1.51 | 96643012 | ||||
| CHAL PRO LED3000-830 HF E3 RMB W6 | 25 | 2900 | LED | 1.51 | 96642366 | ||||
| CHAL PRO LED3000-830 HF E3TX RMB W6 | 25 | 2900 | LED | 1.51 | 96643013 | ||||
| CHAL PRO LED3000-840 HF E3 RMB W6 | 25 | 3030 | LED | 1.51 | 96642367 | ||||
| CHAL PRO LED3000-840 HF E3TX RMB W6 | 25 | 3030 | LED | 1.51 | 96643014 |
▼ Chalice Pro-konfigurerade produkter, CRI 80, blank reflektor, dimbar, nödljus
| Beskrivning | Armatureffekt (W) | Armaturljusflöde (lm) | Type | Vikt (kg) | SAP nummer | ||||
|---|---|---|---|---|---|---|---|---|---|
| CHAL PRO LED1100-830 HFIX E3 RMB W6 | 9 | 1090 | LED | 1.51 | 96642368 | ||||
| CHAL PRO LED1100-830 HFIX E3TX RMB W6 | 9 | 1090 | LED | 1.51 | 96643015 | ||||
| CHAL PRO LED1100-840 HFIX E3 RMB W6 | 9 | 1100 | LED | 1.51 | 96642369 | ||||
| CHAL PRO LED1100-840 HFIX E3TX RMB W6 | 9 | 1100 | LED | 1.51 | 96643016 | ||||
| CHAL PRO LED2000-830 HFIX E3 RMB W6 | 16 | 1900 | LED | 1.51 | 96642370 | ||||
| CHAL PRO LED2000-830 HFIX E3TX RMB W6 | 16 | 1900 | LED | 1.51 | 96643017 | ||||
| CHAL PRO LED2000-840 HFIX E3 RMB W6 | 16 | 2030 | LED | 1.51 | 96642371 | ||||
| CHAL PRO LED2000-840 HFIX E3TX RMB W6 | 16 | 2030 | LED | 1.51 | 96643018 | ||||
| CHAL PRO LED3000-830 HFIX E3 RMB W6 | 25 | 2900 | LED | 1.51 | 96642372 | ||||
| CHAL PRO LED3000-830 HFIX E3TX RMB W6 | 25 | 2900 | LED | 1.51 | 96643019 | ||||
| CHAL PRO LED3000-840 HFIX E3 RMB W6 | 25 | 3030 | LED | 1.51 | 96642373 | ||||
| CHAL PRO LED3000-840 HFIX E3TX RMB W6 | 25 | 3030 | LED | 1.51 | 96643020 |
▼ Chalice Pro-konfigurerade produkter, CRI 80, matt reflektor
| Beskrivning | Armatureffekt (W) | Armaturljusflöde (lm) | Type | Vikt (kg) | SAP nummer | ||||
|---|---|---|---|---|---|---|---|---|---|
| CHAL PRO LED1100-830 HF RSB W6 | 9 | 1090 | LED | 0.49 | 96642326 | ||||
| CHAL PRO LED1100-840 HF RSB W6 | 9 | 1100 | LED | 0.49 | 96642327 | ||||
| CHAL PRO LED2000-830 HF RSB W6 | 16 | 1900 | LED | 0.49 | 96642328 | ||||
| CHAL PRO LED2000-840 HF RSB W6 | 16 | 2030 | LED | 0.49 | 96642329 | ||||
| CHAL PRO LED3000-830 HF RSB W6 | 25 | 2900 | LED | 0.49 | 96642330 | ||||
| CHAL PRO LED3000-840 HF RSB W6 | 25 | 3030 | LED | 0.49 | 96642331 |
▼ Chalice Pro-konfigurerade produkter, CRI 80, matt reflektor, nödljus
| Beskrivning | Armatureffekt (W) | Armaturljusflöde (lm) | Type | Vikt (kg) | SAP nummer | ||||
|---|---|---|---|---|---|---|---|---|---|
| CHAL PRO LED1100-830 HF E3 RSB W6 | 9 | 1090 | LED | 1.51 | 96642338 | ||||
| CHAL PRO LED1100-830 HF E3TX RSB W6 | 9 | 1090 | LED | 1.51 | 96628066 | ||||
| CHAL PRO LED1100-840 HF E3 RSB W6 | 9 | 1100 | LED | 1.51 | 96642339 | ||||
| CHAL PRO LED1100-840 HF E3TX RSB W6 | 9 | 1100 | LED | 1.51 | 96628067 | ||||
| CHAL PRO LED2000-830 HF E3 RSB W6 | 16 | 1900 | LED | 1.51 | 96642340 | ||||
| CHAL PRO LED2000-830 HF E3TX RSB W6 | 16 | 1900 | LED | 1.51 | 96628068 | ||||
| CHAL PRO LED2000-840 HF E3 RSB W6 | 16 | 2030 | LED | 1.51 | 96642341 | ||||
| CHAL PRO LED2000-840 HF E3TX RSB W6 | 16 | 2030 | LED | 1.51 | 96642901 | ||||
| CHAL PRO LED3000-830 HF E3 RSB W6 | 25 | 2900 | LED | 1.51 | 96642342 | ||||
| CHAL PRO LED3000-830 HF E3TX RSB W6 | 25 | 2900 | LED | 1.51 | 96642902 | ||||
| CHAL PRO LED3000-840 HF E3 RSB W6 | 25 | 3030 | LED | 1.51 | 96642343 | ||||
| CHAL PRO LED3000-840 HF E3TX RSB W6 | 25 | 3030 | LED | 1.51 | 96642903 |
▼ Chalice Pro-konfigurerade produkter, CRI 80, matt reflektor, dimbar, nödbelysning
| Beskrivning | Armatureffekt (W) | Armaturljusflöde (lm) | Type | Vikt (kg) | SAP nummer | ||||
|---|---|---|---|---|---|---|---|---|---|
| CHAL PRO LED1100-830 HFIX E3 RSB W6 | 9 | 1090 | LED | 1.51 | 96642344 | ||||
| CHAL PRO LED1100-830 HFIX E3TX RSB W6 | 9 | 1090 | LED | 1.51 | 96642904 | ||||
| CHAL PRO LED1100-840 HFIX E3 RSB W6 | 9 | 1100 | LED | 1.51 | 96642345 | ||||
| CHAL PRO LED1100-840 HFIX E3TX RSB W6 | 9 | 1100 | LED | 1.51 | 96642905 | ||||
| CHAL PRO LED2000-830 HFIX E3 RSB W6 | 16 | 1900 | LED | 1.51 | 96642346 | ||||
| CHAL PRO LED2000-830 HFIX E3TX RSB W6 | 16 | 1900 | LED | 1.51 | 96642906 | ||||
| CHAL PRO LED2000-840 HFIX E3 RSB W6 | 16 | 2030 | LED | 1.51 | 96642347 | ||||
| CHAL PRO LED2000-840 HFIX E3TX RSB W6 | 16 | 2030 | LED | 1.51 | 96642907 | ||||
| CHAL PRO LED3000-830 HFIX E3 RSB W6 | 25 | 2900 | LED | 1.51 | 96642348 | ||||
| CHAL PRO LED3000-830 HFIX E3 RSB WL6 W6 | 25 | 2900 | LED | 1.51 | 92900737 | ||||
| CHAL PRO LED3000-830 HFIX E3TX RSB W6 | 25 | 2900 | LED | 1.51 | 96642908 | ||||
| CHAL PRO LED3000-840 HFIX E3 RSB W6 | 25 | 3030 | LED | 1.51 | 96642349 | ||||
| CHAL PRO LED3000-840 HFIX E3TX RSB W6 | 25 | 3030 | LED | 1.51 | 96642909 |
▼ Chalice Pro-tillbehör
| Beskrivning | Vikt (kg) | SAP nummer | |||||||
|---|---|---|---|---|---|---|---|---|---|
| CHAL 150 FROSTED RING | 0.05 | 96627651 | |||||||
| CHAL 150 HALO RING | 0.17 | 96627650 | |||||||
| CHAL 150 WALLWASHER RMB W6 | 0.17 | 96628054 | |||||||
| CHAL 150 WALLWASHER RSB W6 | 0.17 | 96627652 |
